Nick Featherstone (January, 2018)

NOTE: This document can be viewed in PDF or HTML (recommended) form. It can also be run as an interactive Jupyter notebook.

The HTML and PDF versions are located in Rayleigh/doc/Diagnostic_Plotting.{html,pdf}
The Jupyter notebook is located in Rayleigh/post_processing/Diagnostic_Plotting.ipynb
Standalone Python example scripts for each output type may also found in Rayleigh/post_processing/

Contents¶

Running a Benchmark with Sample Output
Configuring your Python environment
Overview of Rayleigh’s Diagnostic Package
Global Averages
Shell Averages
Azimuthal Averages
Simulation Slices
Spherical Harmonic Spectra
Point Probes
Modal Outputs

I. Running a Benchmark with Sample Output¶

Before you can plot data, you will need to generate data. The code samples in this notebook assume that you have run the model described by the input file found in:

rayleigh/input_examples/benchmark_diagnostics_input

This input file instructs Rayleigh to run the Christensen et al. (2001) hydrodynamic (case 0) benchmark. Running this model with the prescribed outputs will generate approximately 70 MB of data.

To run this model: 1. Create a directory for your simulation (e.g., mkdir my_test_run) 2. Copy the input file: cp rayleigh/input_examples/benchmark_diagnostics_input my_test_run/main_input 3. Copy or soft-link the rayleigh executable: cp Rayleigh/bin/rayleigh.opt my_test_run/. 4. Run the code: mpiexec -np N ./rayleigh -nprow n -npcol m (choose values of {N,n,m} such that n x m = N)

The code will run for 40,000 timesteps, or four viscous diffusion times. While it runs, Rayleigh will perform an in-situ analysis of the accuracy benchmark. Reports are written once every 1,000 time steps and are stored in the Benchmark_Reports subdirectory. Examine file 00030000 and ensure that you see similar results to those below. Your exact numbers may differ slightly, but all quantities should be under 1% difference.

Observable	Measured	Suggested	% Difference	Std. Dev.
Kinetic Energy	58.347827	58.348000	-0.000297	0.000000
Temperature	0.427424	0.428120	-0.162460	0.000101
Vphi	-10.119483	-10.157100	-0.370356	0.013835
Drift Frequency	0.183016	0.182400	0.337630	0.007295

If necessary, copy the data to the system on which you intend to conduct your analysis. Before you can plot, you will need to configure your Python environment.

II. Configuring Your Python Environment¶

Rayleigh comes packaged with a Python library (rayleigh_diagnostics.py) that provides data structures and methods associated with each type of diagnostic output in Rayleigh. This library relies on Numpy and is compatible with Python 3.x or 2.x (The print function is imported from the *future* module).

If you wish to follow along with the plotting examples described in this document, you will need to have the Numpy, Matplotlib, and (optionally) Basemap Python packages installed. The following versions of these packages were used when creating these examples: * Matplotlib v2.0.2 * Numpy v1.13.1 * Basemap v1.0.7

Unless you are experienced at installing and managing Python packages, I recommend setting up a virtual environment for Python using Conda. You may also install the required packages manually, but the advantage of this approach is that you maintain an entirely separate version of Python and related packages for this project. Below are directions for setting up a Python/Conda environment with Intel-optimized Python packages on a Linux system (Mac and Windows work similarly).

Conda Installation on Linux Systems¶

**Step 1: ** Download the appropriate Miniconda installation script from https://conda.io/miniconda.html (choose Python 3.x)

Step 2: ** Make the shell script executable via: **chmod +x Miniconda3-latest-Linux-x86_64.sh (or similar script name)

Step 3: ** Run the installation script: **./Miniconda3-latest-Linux-x86_64.sh

NOTE: The default installation directory is your home directory. This is also where Python packages for your Conda environments will be installed. Avoid installing to a disk with limited space (user home directories on HPC systems are often limited to a few GB).

NOTE: Unless you have a specific reason not to do so, answer “yes” to the question concerning prepending to PATH.

Step 5: ** Update your Conda: **conda update conda

Step 6: ** Add the Intel Conda channel: **conda config –add channels intel

Step 7: ** Create a virtual environment for Intel’s Conda distribution: **conda create -n idp intelpython3_full python=3

NOTE: In this case, idp will be your virtual environment name. You are free to pick an alternative when running conda create.

NOTE: A number of Python packages will be downloaded, including Numpy and Matplotlib. The process may appear to hang at the last step. Be patient.

Step 8: ** Activate your virtual environment: **source activate idp

Step 9: ** Install the Basemap package: **conda install -c intel basemap

Step 10: ** Verify your installation. Type **python and then type the following commands at the prompt: 1. import numpy 2. import matplotlib 3. import mpl_tookits.basemap

If those commands worked without error, you may close Python ( type exit() ). You can revert to your native environment by typing source deactivate (or just close the terminal). Whenever you wish to access your newly-installed Python, type source activate idp first, before running python.

Preparing to Plot¶

All examples in this document rely on the rayleigh_diagnostics module. This module is located in Rayleigh/post_processing, along with several standalone scripts copies from the individual sections of this document. For example, the script plot_G_Avgs.py contains the code from section IV below. All python files you wish to use will need to reside in either your run directory (recommended) or a directory within your PYTHONPATH.

We suggest copying all python files to your my_test_run directory: 1. cp Rayleigh/post_processing/.py my_test_run/. 2. cp Rayleigh/post_processing/.ipynb my_test_run/.

The Jupyter Notebook¶

This document resides in three places: 1. Rayleigh/doc/Diagnostic_Plotting.pdf 2. Rayleigh/doc/Diagnostic_Plotting.html 3. Rayleigh/post_processing/Diagnostic_Plotting.ipynb

The third file is a Jupyter notebook file. This source code was used to generate the html and pdf documents. The notebook is designed to be run from within a Rayleigh simulation directory. If you wish to follow along interactively, copy the Jupyter notebook file from Rayleigh/post_processing/ into your Rayleigh simulation directory (step 2 from Preparing to Plot). You can run the file in Jupyter via: 1. source activate idp 2. jupyter notebook (from within your my_test_run directory) 3. select Diagnostic_Plotting.ipynb in the file menu that presents itself.

When finished: 1. To close the notebook, type ctrl+c and enter “yes” when prompted to shut down the notebook server. 2. type source deactivate

III. Overview of Diagnostics in Rayleigh¶

Rayleigh’s diagnostics package facilitates the in-situ analysis of a simulation using a variety of sampling methods. Each sampling method may be applied to a unique set of sampled quantities. Sampling methods are hereafter referred to as output types and sampled quantities as output variables.

Files of each output type are stored in a similarly-named subdirectory within the Rayleigh simulation directory. Output files are numbered by the time step of the final data record stored in the file. Output behavior for each simulation is controlled through the main_input file. For each output type, the user specifies the output variables, cadence, records-per-file, and other properties by modifying the appropriate variables in the output_namelist section of main_input.

Basic Output Control¶

Each output type in Rayleigh has at least three namelist variables that govern its behavior:

**{OutputType}_values**: comma-separated list of menu codes corresponding to the desired output variables

**{OutputType}_frequency**: integer value that determines how often this type of output is performed

**{OutputType}_nrec**: integer value that determines how many records are stored in each output file.

All possible output variables and their associated menu codes are described in rayleigh/doc/rayleigh_output_variables.pdf You may find it useful to have that document open while following along with examples in this notebook.

As an example of how these variables work, suppose that we want to occasionally output equatorial cuts (output type) of temperature, kinetic energy density, and radial velocity (output variables). At the same time, we might wish to dump full-volume averages (output type) of kinetic and magnetic energy (output variables) with a higher cadence. In that case, something similar to the following would appear in main_input:

globalavg_values = 401, 1101
globalavg_frequency = 50
globalavg_nrec = 100

equatorial_values = 1, 401, 501
equatorial_frequency = 2500
equatorial_nrec = 2

This tells Rayleigh to output full-volume-averages of kinetic energy density (value code 401) and magnetic energy density (value code 1101) once every 50 time steps, with 100 records per file. Files are named based on the time step number of their final record. As a result, information from time steps 50, 100, 150, …, 4950, 5000 will be stored in the file named G_Avgs/00005000. Time steps 5050 through 10,000 will stored in G_Avgs/00010000, and so on.

For the equatorial cuts, Rayleigh will output radial velocity (code 1), the kinetic energy density (code 401) and temperature (code 501) in the equatorial plane once every 2,500 time steps, storing two time steps per file. Data from time steps 2,500 and 5,000 will be stored in Equatorial_Slices/00005000. Data from time steps 7,500 and 10,000 will be stored in Equatorial_Slices/00010000 , and so on.

This general organizational scheme for output was adapted from that developed by Thomas Clune for the ASH code.

Positional Output Control¶

Many of Rayleigh’s output types allow the user to specify a set of gridpoints at which to sample the simulation. A user can, for example, output spherical surfaces sampled at arbitrary radii, or a meridional plane sampled at a specific longitude. This behavior is controlled through additional namelist variables; we refer to these variables as positional specifiers. In the sections that follow, positional specifiers associated with a given output type, if any, will be defined.

Positional specifiers are either indicial or normalized. In the main_input file, indicial specifiers can be assigned a comma-separated list of grid indices on which to perform the output. For example,

shellslice_levels = 1, 32, 64, 128

instructs Rayleigh to output shell slices at { radius[1], radius[32], radius[64], radius[128]}. Note that radius[1] is the outer boundary.

While useful in some situations, specifying indices can lead to confusion if a simulations resolution needs to be changed at some point during a model’s evolution. For example if the radial grid initially had 128 points, index 128 would correspond to the lower boundary. If the resolution were to double, index 128 would correspond to mid-shell.

For this reason, all positional specifiers may also be written in normalized form. Instead of integers, the normalized specifier is assigned a comma separated list of real values in the range [0,1]. The value of zero corresponds to the lowest-value grid coordinate (e.g., the inner radial boundary or theta=0 pole). The value 1 corresponds to the maximal coordinate (e.g., the outer radial boundary or theta=pi pole). A value of 0.5 corresponds to mid-domain. Normalized coordinates are indicated by adding *_nrm* to the indicial specifier’s name. For example,

shellslice_levels_nrm= 0, 0.5, 0.95

instructs Rayleigh to output shell slices at the lower boundary, mid-shell, and slightly below the upper boundary. Rayleigh does not interpolate, but instead picks the grid coordinate closest to each specified normalized coordinate.

We recommend using normalized coordinates to avoid inconsistencies between restarts. They also overcome difficulties associated with the non-uniform nature of the radial and theta grids wherein grid points cluster near the boundaries.

Positional Ranges Ranges of coordinates can be specified using shorthand, if desired. The inclusive coordinate range [X,Y] is indicated by a positive/negative number pair appearing in the indicial or normalized coordinate list. Multiple ranges can be specified within a list. For example,

shellslice_levels = 1,10,-15, 16, 20,-25, 128

would instruct Rayleigh to output shell slices at radial indices = { 1, 10, 11, 12, 13, 14, 15, 16, 20, 21, 22, 23, 24, 25, 128}

Similarly,

shellslice_levels_nrm = 0,-0.5, 1.0

instructs Rayleigh to output shells at all radii in the lower half of the domain, and at the outer boundary.

IV. Global Averages¶

Summary: Full-volume averages of requested output variables over the full, spherical shell

Subdirectory: G_Avgs

main_input prefix: globalavg

Python Class: G_Avgs

Additional Namelist Variables:

None

Before proceeding, ensure that you have copied Rayleigh/post_processing/rayleigh_diagnostics.py to your simulation directory. This Python module is required for reading Rayleigh output into Python.

Examining the main_input file, we see that the following output values have been denoted for the Global Averages (see rayleigh_output_variables.pdf for the mathematical formulae):

Menu Code	Description
401	Full Kinetic Energy Density (KE)
402	KE (radial motion)
403	KE (theta motion)
404	KE (phi motion)
405	Mean Kinetic Energy Density (MKE)
406	MKE (radial motion)
407	MKE (theta motion)
408	MKE (phi motion)
409	Fluctuating Kinetic Energy Density (FKE)
410	FKE (radial motion)
411	FKE (theta motion)
412	FKE (phi motion)

In the example that follows, we will plot the time-evolution of these different contributions to the kinetic energy budget. We begin with the following preamble:

[1]:

%matplotlib inline
from rayleigh_diagnostics import G_Avgs, build_file_list
import matplotlib.pyplot as plt
import numpy

The preamble for each plotting example will look similar to that above. We import the numpy and matplotlib.pyplot modules, aliasing the latter to plt. We also import two items from rayleigh_diagnostics: a helper function build_file_list and the GlobalAverage class.

The G_Avgs class is the Python class that corresponds to the full-volume averages stored in the G_Avgs subdirectory of each Rayleigh run.

We will use the build_file_list function in many of the examples that follow. It’s useful when processing a time series of data, as opposed to a single snapshot. This function accepts three parameters: a beginning time step, an ending time step, and a subdirectory (path). It returns a list of all files found in that directory that lie within the inclusive range [beginning time step, ending time step]. The file names are prepended with the subdirectory name, as shown below.

[2]:

# Build a list of all files ranging from iteration 0 million to 1 million
files = build_file_list(0,1000000,path='G_Avgs')
print(files)

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-4eb2f8895736> in <module>
      1 # Build a list of all files ranging from iteration 0 million to 1 million
----> 2 files = build_file_list(0,1000000,path='G_Avgs')
      3 print(files)

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in build_file_list(istart, iend, path, diter, ndig, special)
   1501     if (diter < 1):
   1502         # Examine the directory and grab all files that fall between istart and iend
-> 1503         allfiles = os.listdir(path)
   1504         allfiles.sort()
   1505         for f in allfiles:

FileNotFoundError: [Errno 2] No such file or directory: 'G_Avgs'

We can create an instance of the G_Avgs class by initializing it with a filename. The optional keyword parameter path is used to specify the directory. If path is not specified, its value will default to the subdirectory name associated with the datastructure (G_Avgs in this instance).

Each class was programmed with a docstring describing the class attributes. Once you created an instance of a rayleigh_diagnostics class, you can view its attributes using the help function as shown below.

[3]:

a = G_Avgs(filename=files[0],path='')  # Here, files[0]='G_Avgs/00010000'
#a= G_Avgs(filename='00010000') would yield an equivalent result
help(a)

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-40d3193982f4> in <module>
----> 1 a = G_Avgs(filename=files[0],path='')  # Here, files[0]='G_Avgs/00010000'
      2 #a= G_Avgs(filename='00010000') would yield an equivalent result
      3 help(a)

NameError: name 'files' is not defined

Examining the docstring, we see a few important attributes that are common to the other outputs discussed in this document: 1. niter – the number of time steps in the file 2. nq – the number of output variables stored in the file 3. qv – the menu codes for those variables 4. vals – the actual data 5. time – the simulation time corresponding to each output dump

The first step in plotting a time series is to collate the data.

[4]:

# Loop over all files and concatenate their data into a single array
nfiles = len(files)
for i,f in enumerate(files):
    a = G_Avgs(filename=f,path='')
    if (i == 0):
        nq = a.nq
        niter = a.niter
        gavgs = numpy.zeros((niter*nfiles,nq),dtype='float64')
        iters = numpy.zeros(niter*nfiles,dtype='int32')
        time = numpy.zeros(niter*nfiles,dtype='float64')
    i0 = i*niter
    i1 = (i+1)*niter
    gavgs[i0:i1,:] = a.vals
    time[i0:i1] = a.time
    iters[i0:i1] = a.iters

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-f0ee4917e44f> in <module>
      1 # Loop over all files and concatenate their data into a single array
----> 2 nfiles = len(files)
      3 for i,f in enumerate(files):
      4     a = G_Avgs(filename=f,path='')
      5     if (i == 0):

NameError: name 'files' is not defined

The Lookup Table (LUT)¶

The next step in the process is to identify where within the gavgs array our deisired output variables reside. Every Rayleigh file object possesses a lookup table (lut). The lookup table is a python list used to identify the index within the vals array where a particular menu code resides. For instance, the menu code for the theta component of the velocity is 2. The location of v_theta in the vals array is then stored in lut[2].

Note that you should never assume that output variables are stored in any particular order. Moreover, the lookup table is unique to each file and is likely to change during a run if you modify the output variables in between restarts. When running the benchmark, we kept a consistent set of outputs throughout the entirety of the run. This means that the lookup table did not change between outputs and that we can safely use the final file’s lookup table (or any other file’s table) to reference our data.

Plotting Kinetic Energy¶

Let’s examine the different contributions to the kinetic energy density in our models. Before we can plot, we should use the lookup table to identify the location of each quantity we are interested in plotting.

[5]:

#The indices associated with our various outputs are stored in a lookup table
#as part of the GlobalAverage data structure.  We define several variables to
#hold those indices here:

lut = a.lut
ke  = lut[401]  # Kinetic Energy (KE)
rke = lut[402]  # KE associated with radial motion
tke = lut[403]  # KE associated with theta motion
pke = lut[404]  # KE associated with azimuthal motion

#We also grab some energies associated with the mean (m=0) motions
mke  = lut[405]
mrke = lut[406]  # KE associated with mean radial motion
mtke = lut[407]  # KE associated with mean theta motion
mpke = lut[408]  # KE associated with mean azimuthal motion

#We also output energies associated with the fluctuating/nonaxisymmetric
#motions (e.g., v- v_{m=0})
fke  = lut[409]
frke = lut[410]  # KE associated with mean radial motion
ftke = lut[411]  #KE associated with mean theta motion
fpke = lut[412]  # KE associated with mean azimuthal motion

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-1d4f0918aa0f> in <module>
      3 #hold those indices here:
      4
----> 5 lut = a.lut
      6 ke  = lut[401]  # Kinetic Energy (KE)
      7 rke = lut[402]  # KE associated with radial motion

NameError: name 'a' is not defined

To begin with, let’s plot the total, mean, and fluctuating kinetic energy density during the initial transient phase, and then during the equilibrated phase.

[6]:

sizetuple=(10,3)
fig, ax = plt.subplots(ncols=2, figsize=sizetuple)
ax[0].plot(time, gavgs[:,ke], label='KE')
ax[0].plot(time, gavgs[:,mke],label='MKE')
ax[0].plot(time, gavgs[:,fke], label='FKE')
ax[0].legend(loc='center right', shadow=True)
ax[0].set_xlim([0,0.2])
ax[0].set_title('Equilibration Phase')
ax[0].set_xlabel('Time')
ax[0].set_ylabel('Energy')

ax[1].plot(time, gavgs[:,ke], label='KE')
ax[1].plot(time, gavgs[:,mke], label = 'MKE')
ax[1].plot(time,gavgs[:,fke],label='FKE')
ax[1].legend(loc='center right', shadow=True)
ax[1].set_title('Entire Time-Trace')
ax[1].set_xlabel('Time')
ax[1].set_ylabel('Energy')

saveplot = False # Plots appear in the notebook and are not written to disk (set to True to save to disk)
savefile = 'energy_trace.pdf'  #Change .pdf to .png if pdf conversion gives issues
plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-f38f01f3d0ff> in <module>
      1 sizetuple=(10,3)
      2 fig, ax = plt.subplots(ncols=2, figsize=sizetuple)
----> 3 ax[0].plot(time, gavgs[:,ke], label='KE')
      4 ax[0].plot(time, gavgs[:,mke],label='MKE')
      5 ax[0].plot(time, gavgs[:,fke], label='FKE')

NameError: name 'time' is not defined

../_images/post_processing_Diagnostic_Plotting_15_1.png

We can also look at the energy associated with each velocity component. Note that we log scale in the last plot. There is very little mean radial or theta kinetic energy; it is mostly phi energy.

[7]:

sizetuple=(5,10)
xlims=[0,0.2]
fig, ax = plt.subplots(ncols=1, nrows=3, figsize=sizetuple)
ax[0].plot(time, gavgs[:,ke], label='KE')
ax[0].plot(time, gavgs[:,rke],label='RKE')
ax[0].plot(time, gavgs[:,tke], label='TKE')
ax[0].plot(time, gavgs[:,pke], label='PKE')
ax[0].legend(loc='center right', shadow=True)
ax[0].set_xlim(xlims)
ax[0].set_title('Total KE Breakdown')
ax[0].set_xlabel('Time')
ax[0].set_ylabel('Energy')

ax[1].plot(time, gavgs[:,fke],  label='FKE')
ax[1].plot(time, gavgs[:,frke], label='FRKE')
ax[1].plot(time, gavgs[:,ftke], label='FTKE')
ax[1].plot(time, gavgs[:,fpke], label='FPKE')
ax[1].legend(loc='center right', shadow=True)
ax[1].set_xlim(xlims)
ax[1].set_title('Fluctuating KE Breakdown')
ax[1].set_xlabel('Time')
ax[1].set_ylabel('Energy')

ax[2].plot(time, gavgs[:,mke],  label='MKE')
ax[2].plot(time, gavgs[:,mrke], label='MRKE')
ax[2].plot(time, gavgs[:,mtke], label='MTKE')
ax[2].plot(time, gavgs[:,mpke], label='MPKE')
ax[2].legend(loc='lower right', shadow=True)
ax[2].set_xlim(xlims)
ax[2].set_title('Mean KE Breakdown')
ax[2].set_xlabel('Time')
ax[2].set_ylabel('Energy')
ax[2].set_yscale('log')

plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-131fad98d736> in <module>
      2 xlims=[0,0.2]
      3 fig, ax = plt.subplots(ncols=1, nrows=3, figsize=sizetuple)
----> 4 ax[0].plot(time, gavgs[:,ke], label='KE')
      5 ax[0].plot(time, gavgs[:,rke],label='RKE')
      6 ax[0].plot(time, gavgs[:,tke], label='TKE')

NameError: name 'time' is not defined

../_images/post_processing_Diagnostic_Plotting_17_1.png

V. Shell Averages¶

Summary: Spherical averages of requested output variables. Each output variable is stored as a 1-D function of radius.

Subdirectory: Shell_Avgs

main_input prefix: shellavg

Python Class: Shell_Avgs

Additional Namelist Variables:

None

The Shell-Averaged outputs are useful for examining how quantities vary as a function of radius. They are particularly useful for examining the distribution of energy as a function of radius, or the heat flux balance established by the system.

Examining the main_input file, we see that the following output values have been denoted for the Shell Averages (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity
501	Temperature Perturbation
1438	Radial Convective Heat Flux
1468	Radial Conductive Heat Flux

In the example that follows, we will plot the spherically-averaged velocity field as a function of radius, the mean temperature profile, and the radial heat flux. We begin with a preamble similar to that used for the Global Averages. Using the help function, we see that the Shell_Avgs data structure is similar to that of the G_Avgs. There are three important differences: * There is a radius attribute (necessary if we want to plot anything vs. radius) * The dimensionality of the values array has changed; radial index forms the first dimension. * The second dimension of the values array has a length of 4. In addition to the spherical mean, the 1st, 2nd and 3rd moments are stored in indices 0,1,2, and 3 respectively.

[8]:

from rayleigh_diagnostics import Shell_Avgs, build_file_list
import matplotlib.pyplot as plt
import numpy

# Build a list of all files ranging from iteration 0 million to 1 million
files = build_file_list(0,1000000,path='Shell_Avgs')
a = Shell_Avgs(filename=files[0], path='')
help(a)

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-656db1bb32ea> in <module>
      4
      5 # Build a list of all files ranging from iteration 0 million to 1 million
----> 6 files = build_file_list(0,1000000,path='Shell_Avgs')
      7 a = Shell_Avgs(filename=files[0], path='')
      8 help(a)

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in build_file_list(istart, iend, path, diter, ndig, special)
   1501     if (diter < 1):
   1502         # Examine the directory and grab all files that fall between istart and iend
-> 1503         allfiles = os.listdir(path)
   1504         allfiles.sort()
   1505         for f in allfiles:

FileNotFoundError: [Errno 2] No such file or directory: 'Shell_Avgs'

While it can be useful to look at instaneous snapshots of Shell Averages, it’s often useful to examine these outputs in a time-averaged sense. Let’s average of all 200 snapshots in the last file that was output. We could average over data from multiple files, but since the benchmark run achieves a nearly steady state, a single file will do in this case.

[9]:

nfiles = len(files)

nr = a.nr
nq = a.nq
nmom = 4
niter = a.niter
radius = a.radius
savg=numpy.zeros((nr,nmom,nq),dtype='float64')
for i in range(niter):
    savg[:,:,:] += a.vals[:,:,:,i]
savg = savg*(1.0/niter)

lut = a.lut
vr = lut[1]        # Radial Velocity
vtheta = lut[2]    # Theta Velocity
vphi = lut[3]      # Phi Velocity
thermal = lut[501] # Temperature


eflux = lut[1440]  # Convective Heat Flux (radial)
cflux = lut[1470]  # Conductive Heat Flux (radial)

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-2cc54334186f> in <module>
----> 1 nfiles = len(files)
      2
      3 nr = a.nr
      4 nq = a.nq
      5 nmom = 4

NameError: name 'files' is not defined

Velocity vs. Radius¶

Next, we plot the mean velocity field, and its first moment, as a function of radius. Notice that the radial and theta velocity components have a zero spherical mean. Since we are running an incompressible model, this is a good sign!

[10]:

sizetuple = (7,7)
fig, ax = plt.subplots(nrows=2, ncols =1, figsize=sizetuple)

ax[0].plot(radius,savg[:,0,vr],label=r'$v_r$')
ax[0].plot(radius,savg[:,0,vtheta], label=r'$v_\theta$')
ax[0].plot(radius,savg[:,0,vphi], label=r'$v_\phi$')
ax[0].legend(shadow=True,loc='lower right')
ax[0].set_xlabel('Radius')
ax[0].set_ylabel('Velocity')
ax[0].set_title('Spherically-Averaged Velocity Components')

ax[1].plot(radius,savg[:,1,vr],label=r'$v_r$')
ax[1].plot(radius,savg[:,1,vtheta], label=r'$v_\theta$')
ax[1].plot(radius,savg[:,1,vphi], label=r'$v_\phi$')
ax[1].legend(shadow=True,loc='upper left')
ax[1].set_xlabel('Radius')
ax[1].set_ylabel('Velocity')
ax[1].set_title('Velocity Components: First Spherical Moment')


plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-0e45d2fe2ea5> in <module>
      2 fig, ax = plt.subplots(nrows=2, ncols =1, figsize=sizetuple)
      3
----> 4 ax[0].plot(radius,savg[:,0,vr],label=r'$v_r$')
      5 ax[0].plot(radius,savg[:,0,vtheta], label=r'$v_\theta$')
      6 ax[0].plot(radius,savg[:,0,vphi], label=r'$v_\phi$')

NameError: name 'radius' is not defined

../_images/post_processing_Diagnostic_Plotting_23_1.png

Radial Temperature Profile¶

We might also look at temperature …

[11]:

fig, ax = plt.subplots()

ax.plot(radius,savg[:,0,thermal],label='Temperature (mean)')
ax.plot(radius,savg[:,1,thermal]*10, label='Temperature (standard dev.)')
ax.legend(shadow=True,loc='upper right')
ax.set_xlabel('Radius')
ax.set_ylabel('Temperature')
ax.set_title('Radial Temperature Profile')


plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-f2901fa62706> in <module>
      1 fig, ax = plt.subplots()
      2
----> 3 ax.plot(radius,savg[:,0,thermal],label='Temperature (mean)')
      4 ax.plot(radius,savg[:,1,thermal]*10, label='Temperature (standard dev.)')
      5 ax.legend(shadow=True,loc='upper right')

NameError: name 'radius' is not defined

Heat Flux Contributions¶

We can also examine the balance between convective and conductive heat flux. In this case, before plotting these quantities as a function of radius, we normalize them by the surface area of the sphere to form a luminosity.

[12]:

fpr=4.0*numpy.pi*radius*radius
elum = savg[:,0,eflux]*fpr
clum = savg[:,0,cflux]*fpr
tlum = elum+clum
fig, ax = plt.subplots()
ax.plot(radius,elum,label='Convection')
ax.plot(radius,clum, label='Conduction')
ax.plot(radius,tlum, label='Total')
ax.set_title('Flux Balance')
ax.set_ylabel(r'Energy Flux ($\times 4\pi r^2$)')
ax.set_xlabel('Radius')
ax.legend(shadow=True)
plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-111e4e5dbb14> in <module>
----> 1 fpr=4.0*numpy.pi*radius*radius
      2 elum = savg[:,0,eflux]*fpr
      3 clum = savg[:,0,cflux]*fpr
      4 tlum = elum+clum
      5 fig, ax = plt.subplots()

NameError: name 'radius' is not defined

VI. Azimuthal Averages¶

Summary: Azimuthal averages of requested output variables. Each output variable is stored as a 2-D function of radius and latitude.

Subdirectory: AZ_Avgs

main_input prefix: azavg

Python Class: AZ_Avgs

Additional Namelist Variables:

None

Azimuthally-Averaged outputs are particularly useful for examining a system’s mean flows (i.e., differential rotation and meridional circulation).

Examining the main_input file, we see that the following output values have been denoted for the Azimuthal Averages (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity
201	Radial Mass Flux
202	Theta Mass Flux
501	Temperature Perturbation

In the example that follows, we demonstrate how to plot azimuthal averages, including how to generate streamlines of mass flux. Note that since the benchmark is Boussinesq, our velocity and mass flux fields are identical. This is not the case when running an anelastic simulation.

We begin with the usual preamble and also import two helper routines used for displaying azimuthal averages.

Examining the data structure, we see that the vals array is dimensioned to account for latitudinal variation, and that we have new attributes costheta and sintheta used for referencing locations in the theta direction.

[13]:

from rayleigh_diagnostics import AZ_Avgs, build_file_list, plot_azav, streamfunction
import matplotlib.pyplot as plt
import pylab
import numpy
#from azavg_util import *
files = build_file_list(30000,40000,path='AZ_Avgs')
az = AZ_Avgs(files[0],path='')
help(az)

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-6e0dc3c707b5> in <module>
      4 import numpy
      5 #from azavg_util import *
----> 6 files = build_file_list(30000,40000,path='AZ_Avgs')
      7 az = AZ_Avgs(files[0],path='')
      8 help(az)

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in build_file_list(istart, iend, path, diter, ndig, special)
   1501     if (diter < 1):
   1502         # Examine the directory and grab all files that fall between istart and iend
-> 1503         allfiles = os.listdir(path)
   1504         allfiles.sort()
   1505         for f in allfiles:

FileNotFoundError: [Errno 2] No such file or directory: 'AZ_Avgs'

Before creating our plots, let’s time-average over the last two files that were output (thus sampling the equilibrated phase).

[14]:

nfiles = len(files)
tcount=0
for i in range(nfiles):
    az=AZ_Avgs(files[i],path='')

    if (i == 0):
        nr = az.nr
        ntheta = az.ntheta
        nq = az.nq
        azavg=numpy.zeros((ntheta,nr,nq),dtype='float64')

    for j in range(az.niter):
        azavg[:,:,:] += az.vals[:,:,:,j]
        tcount+=1
azavg = azavg*(1.0/tcount)  # Time steps were uniform for this run, so a simple average will suffice

lut = az.lut
vr = azavg[:,:,lut[1]]
vtheta = azavg[:,:,lut[2]]
vphi = azavg[:,:,lut[3]]
rhovr = azavg[:,:,lut[201]]
rhovtheta = azavg[:,:,lut[202]]
temperature = azavg[:,:,lut[501]]
radius = az.radius
costheta = az.costheta
sintheta = az.sintheta

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-1381baa73436> in <module>
----> 1 nfiles = len(files)
      2 tcount=0
      3 for i in range(nfiles):
      4     az=AZ_Avgs(files[i],path='')
      5

NameError: name 'files' is not defined

Before we render, we need to do some quick post-processing: 1. Remove the spherical mean temperature from the azimuthal average. 2. Convert v_phi into omega 3. Compute the magnitude of the mass flux vector 4. Compute stream function associated with the mass flux field

[15]:

#Subtrace the ell=0 component from temperature at each radius
for i in range(nr):
    temperature[:,i]=temperature[:,i] - numpy.mean(temperature[:,i])

#Convert v_phi to an Angular velocity
omega=numpy.zeros((ntheta,nr))
for i in range(nr):
    omega[:,i]=vphi[:,i]/(radius[i]*sintheta[:])

#Generate a streamfunction from rhov_r and rhov_theta
psi = streamfunction(rhovr,rhovtheta,radius,costheta,order=0)
#contours of mass flux are overplotted on the streamfunction PSI
rhovm = numpy.sqrt(rhovr**2+rhovtheta**2)*numpy.sign(psi)

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-bce45d06f32b> in <module>
      1 #Subtrace the ell=0 component from temperature at each radius
----> 2 for i in range(nr):
      3     temperature[:,i]=temperature[:,i] - numpy.mean(temperature[:,i])
      4
      5 #Convert v_phi to an Angular velocity

NameError: name 'nr' is not defined

Finally, we render the azimuthal averages.

NOTE: If you want to save any of these figures, you can mimic the saveplot logic at the bottom of this example.

[16]:

#   We do a single row of 3 images
#   Spacing is default spacing set up by subplot
figdpi=300
sizetuple=(5.5*3,3*3)


tsize = 20     # title font size
cbfsize = 10   # colorbar font size
fig, ax = plt.subplots(ncols=3,figsize=sizetuple,dpi=figdpi)
plt.rcParams.update({'font.size': 14})

#temperature
#ax1 = f1.add_subplot(1,3,1)
units = '(nondimensional)'
plot_azav(fig,ax[0],temperature,radius,costheta,sintheta,mycmap='RdYlBu_r',boundsfactor = 2,
          boundstype='rms', units=units, fontsize = cbfsize)
ax[0].set_title('Temperature',fontsize=tsize)

#Differential Rotation
#ax1 = f1.add_subplot(1,3,2)
units = '(nondimensional)'
plot_azav(fig,ax[1],omega,radius,costheta,sintheta,mycmap='RdYlBu_r',boundsfactor = 1.5,
          boundstype='rms', units=units, fontsize = cbfsize)
ax[1].set_title(r'$\omega$',fontsize=tsize)

#Mass Flux
#ax1 = f1.add_subplot(1,3,3)
units = '(nondimensional)'
plot_azav(fig,ax[2],psi,radius,costheta,sintheta,mycmap='RdYlBu_r',boundsfactor = 1.5,
          boundstype='rms', units=units, fontsize = cbfsize, underlay = rhovm)
ax[2].set_title('Mass Flux',fontsize = tsize)

saveplot=False
if (saveplot):
    p.savefig(savefile)
else:
    plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-70ddce8ff1e5> in <module>
     13 #ax1 = f1.add_subplot(1,3,1)
     14 units = '(nondimensional)'
---> 15 plot_azav(fig,ax[0],temperature,radius,costheta,sintheta,mycmap='RdYlBu_r',boundsfactor = 2,
     16           boundstype='rms', units=units, fontsize = cbfsize)
     17 ax[0].set_title('Temperature',fontsize=tsize)

NameError: name 'temperature' is not defined

../_images/post_processing_Diagnostic_Plotting_35_1.png

VII. Simulation Slices¶

VII.1 Equatorial Slices¶

Summary: 2-D profiles of selected output variables in the equatorial plane.

Subdirectory: Equatorial_Slices

main_input prefix: equatorial

Python Class: Equatorial_Slices

Additional Namelist Variables:

None

The equatorial-slice output type allows us to examine how the fluid properties vary in longitude and radius.

Examining the main_input file, we see that the following output values have been denoted for the Equatorial Slices (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity

In the example that follows, we demonstrate how to create a 2-D plot of radial velocity in the equatorial plane (at a single time step).

We begin with the usual preamble. Examining the data structure, we see that the vals array is dimensioned to account for longitudinal variation, and that we have the new coordinate attribute phi.

[17]:

from rayleigh_diagnostics import Equatorial_Slices
import numpy
import matplotlib.pyplot as plt
from matplotlib import ticker, font_manager
istring = '00040000'
es = Equatorial_Slices(istring)
tindex =1 # Grab second time index from this file
help(es)

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-80e554ed684b> in <module>
      4 from matplotlib import ticker, font_manager
      5 istring = '00040000'
----> 6 es = Equatorial_Slices(istring)
      7 tindex =1 # Grab second time index from this file
      8 help(es)

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in __init__(self, filename, path)
    891         else:
    892             the_file = path+filename
--> 893         fd = open(the_file,'rb')
    894         # We read an integer to assess which endian the file was written in...
    895         bs = check_endian(fd,314,'int32')

FileNotFoundError: [Errno 2] No such file or directory: 'Equatorial_Slices/00040000'

[18]:

################################
# Equatorial Slice
#Set up the grid

remove_mean = True # Remove the m=0 mean
nr = es.nr
nphi = es.nphi
r = es.radius/numpy.max(es.radius)
phi = numpy.zeros(nphi+1,dtype='float64')
phi[0:nphi] = es.phi
phi[nphi] = numpy.pi*2  # For display purposes, it is best to have a redunant data point at 0,2pi

#We need to generate a cartesian grid of x-y coordinates (both X & Y are 2-D)
radius_matrix, phi_matrix = numpy.meshgrid(r,phi)
X = radius_matrix * numpy.cos(phi_matrix)
Y = radius_matrix * numpy.sin(phi_matrix)

qindex = es.lut[1] # radial velocity
field = numpy.zeros((nphi+1,nr),dtype='float64')
field[0:nphi,:] =es.vals[:,:,qindex,tindex]
field[nphi,:] = field[0,:]  #replicate phi=0 values at phi=2pi

#remove the mean if desired (usually a good idea, but not always)
if (remove_mean):
    for i in range(nr):
        the_mean = numpy.mean(field[:,i])
        field[:,i] = field[:,i]-the_mean

#Plot
sizetuple=(8,5)
fig, ax = plt.subplots(figsize=(8,8))
tsize = 20     # title font size
cbfsize = 10   # colorbar font size
img = ax.pcolormesh(X,Y,field,cmap='jet')
ax.axis('equal')  # Ensure that x & y axis ranges have a 1:1 aspect ratio
ax.axis('off')    # Do not plot x & y axes

# Plot bounding circles
ax.plot(r[nr-1]*numpy.cos(phi), r[nr-1]*numpy.sin(phi), color='black')  # Inner circle
ax.plot(r[0]*numpy.cos(phi), r[0]*numpy.sin(phi), color='black')  # Outer circle

ax.set_title(r'$v_r$', fontsize=20)

#colorbar ...
cbar = plt.colorbar(img,orientation='horizontal', shrink=0.5, aspect = 15, ax=ax)
cbar.set_label('nondimensional')

tick_locator = ticker.MaxNLocator(nbins=5)
cbar.locator = tick_locator
cbar.update_ticks()
cbar.ax.tick_params(labelsize=cbfsize)   #font size for the ticks

t = cbar.ax.xaxis.label
t.set_fontsize(cbfsize)  # font size for the axis title


plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-0d8ef134005c> in <module>
      4
      5 remove_mean = True # Remove the m=0 mean
----> 6 nr = es.nr
      7 nphi = es.nphi
      8 r = es.radius/numpy.max(es.radius)

NameError: name 'es' is not defined

VII.2 Meridional Slices¶

Summary: 2-D profiles of selected output variables sampled in meridional planes.

Subdirectory: Meridional_Slices

main_input prefix: meridional

Python Class: Meridional_Slices

Additional Namelist Variables:

meridional_indices (indicial) : indices along longitudinal grid at which to output meridional planes.
meridional_indices_nrm (normalized) : normalized longitudinal grid coordinates at which to output

The meridional-slice output type allows us to examine how the fluid properties vary in latitude and radius.

Examining the main_input file, we see that the following output values have been denoted for the Meridional Slices (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity

In the example that follows, we demonstrate how to create a 2-D plot of radial velocity in a meridional plane. The procedure is similar to that used to plot an azimuthal average.

We begin with the usual preamble and import the plot_azav helper function. Examining the data structure, we see that it is similar to the AZ_Avgs data structure. The vals array possesses an extra dimension relative to its AZ_Avgs counterpart to account for the multiple longitudes that may be output, we see attributes phi and phi_indices have been added to reference the longitudinal grid.

[19]:

#####################################
#  Meridional Slice
from rayleigh_diagnostics import Meridional_Slices, plot_azav
import numpy
import matplotlib.pyplot as plt
from matplotlib import ticker, font_manager
# Read the data

istring = '00040000'
ms = Meridional_Slices(istring)
tindex =1 # All example quantities were output with same cadence.  Grab second time-index from all.
help(ms)

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-2131b4867340> in <module>
      8
      9 istring = '00040000'
---> 10 ms = Meridional_Slices(istring)
     11 tindex =1 # All example quantities were output with same cadence.  Grab second time-index from all.
     12 help(ms)

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in __init__(self, filename, path)
    822         else:
    823             the_file = path+filename
--> 824         fd = open(the_file,'rb')
    825         # We read an integer to assess which endian the file was written in...
    826         bs = check_endian(fd,314,'int32')

FileNotFoundError: [Errno 2] No such file or directory: 'Meridional_Slices/00040000'

[20]:

radius = ms.radius
costheta = ms.costheta
sintheta = ms.sintheta
phi_index = 0  # We only output one Meridional Slice
vr_ms = ms.vals[phi_index,:,:,ms.lut[1],tindex]
units = 'nondimensional'

# Plot
sizetuple=(8,5)
fig, ax = plt.subplots(figsize=(8,8))
tsize = 20     # title font size
cbfsize = 10   # colorbar font size
ax.axis('equal')  # Ensure that x & y axis ranges have a 1:1 aspect ratio
ax.axis('off')    # Do not plot x & y axes
plot_azav(fig,ax,vr_ms,radius,costheta,sintheta,mycmap='RdYlBu_r',boundsfactor = 4.5,
          boundstype='rms', units=units, fontsize = cbfsize)
ax.set_title('Radial Velocity',fontsize=tsize)
plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
<ipython-input-1-85b53260db33> in <module>
----> 1 radius = ms.radius
      2 costheta = ms.costheta
      3 sintheta = ms.sintheta
      4 phi_index = 0  # We only output one Meridional Slice
      5 vr_ms = ms.vals[phi_index,:,:,ms.lut[1],tindex]

NameError: name 'ms' is not defined

VII.3 Shell Slices¶

Summary: 2-D, spherical profiles of selected output variables sampled in at discrete radii.

Subdirectory: Shell_Slices

main_input prefix: shellslice

Python Class: Shell_Slices

Additional Namelist Variables:

shellslice_levels (indicial) : indices along radial grid at which to output spherical surfaces.
shellslice_levels_nrm (normalized) : normalized radial grid coordinates at which to output spherical surfaces.

The shell-slice output type allows us to examine how the fluid properties vary on spherical surfaces.

Examining the main_input file, we see that the following output values have been denoted for the Shell Slices (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity

In the examples that follow, we demonstrate how to create a 2-D plot of radial velocity: * on a Cartesian, lat-lon grid * projected onto a spherical surface using Basemap (MUST set use Basemap=True below)

Plotting on a lat-lon grid is straightforward and illustrated below. The shell-slice data structure is also displayed via the help() function in the example below and contains information needed to define the spherical grid for plotting purposes.

It is worth noting the slice_spec keyword (described in the docstring) that can be passed to the init method. When reading large shell slices, a user can save time and memory during the read process by specifying the slice they want to read.

[21]:

#####################################
#  Shell Slice
from rayleigh_diagnostics import Shell_Slices
import numpy
import matplotlib.pyplot as plt
from matplotlib import ticker, font_manager
# Read the data

istring = '00040000'
ss = Shell_Slices(istring)
help(ss)
ntheta = ss.ntheta
nphi = ss.nphi
costheta = ss.costheta
theta = numpy.arccos(costheta)

#help(ss)
tindex =1 # All example quantities were output with same cadence.  Grab second time-index from all.
rindex = 0 # only output one radius
sizetuple=(8,8)

vr = ss.vals[:,:,rindex,ss.lut[1],tindex]
fig, ax = plt.subplots(figsize=sizetuple)


img = plt.imshow(numpy.transpose(vr), extent=[0,360,-90,90])
ax.set_xlabel( 'Longitude')
ax.set_ylabel( 'Latitude')
ax.set_title(  'Radial Velocity')

plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-17aaac14ede7> in <module>
      8
      9 istring = '00040000'
---> 10 ss = Shell_Slices(istring)
     11 help(ss)
     12 ntheta = ss.ntheta

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in __init__(self, filename, path, slice_spec, rec0)
    984         #slice_spec is [time, qcode, radindex] ; time and rad_index start at 0
    985
--> 986         fd = open(the_file,'rb')
    987         # We read an integer to assess which endian the file was written in...
    988         bs = check_endian(fd,314,'int32')

FileNotFoundError: [Errno 2] No such file or directory: 'Shell_Slices/00040000'

Plotting with Basemap If you wish to project your data onto a spherical grid, we recommend using the Basemap package. If you have not installed this package yet, recall that you can do so by activating your conda environment and then running:

conda install -c intel basemap

The example that follows illustrates how to use Basemap. So that this notebook will run for those without Basemap installed, we have nested the plotting code in a try/except statement. If Basemap fails to import, the code will report an error message instead of crashing.

[22]:

try:
    from mpl_toolkits.basemap import Basemap, addcyclic
    import numpy as np
    import matplotlib.pyplot as plt
    from matplotlib import ticker
    from rayleigh_diagnostics import Shell_Slices

    tsize = 20     # title font size
    cbfsize = 10   # colorbar font size

    #Specify which data to plot
    istring='00040000'
    rec_spec = [1,1,0]  # grab time index 1, quantity code 1, and radial index 0
    ss = Shell_Slices(istring,slice_spec = rec_spec)
    nphi = ss.nphi
    ntheta = ss.ntheta

    save_figure = False # Set to true to save to a figure_file (below)
    figure_file = 'shell_slice_basemap.png'

    #The resolution of the png file or the view window in pixels
    xpixels = 1024
    ypixels = 1024

    # Initialize the projection.
    # lon_0, lat_0 are the center point of the projection.
    # resolution = 'l' means use low resolution coastlines.
    m = Basemap(projection='ortho',lon_0=-20,lat_0=35,resolution='l')


    #Read in the data

    data = ss.vals[:,:,0,0,0].reshape(nphi,ntheta)
    data = np.transpose(data)
    maxabs = 3*np.std(data)  # saturate data at +/- 3 sigma
    dlon = 360.0/(nphi)
    dlat = 180.0/ntheta

    #Scale the data
    for i in range(ntheta):
        for j in range(nphi):
            if (data[i,j] > maxabs):
                data[i,j] = maxabs
            if (data[i,j] < -maxabs):
                data[i,j] = -maxabs
            data[i,j] = data[i,j]/maxabs


    #Generate 1-D grids of latitude and longitude
    lons = np.zeros(nphi)
    for i in range(nphi):
        lons[i] = dlon*i-180.0

    lats = np.zeros(ntheta)
    for i in range(ntheta):
        lats[i] = 90.0-np.arccos(ss.costheta[i])*180.0/np.pi
        lats[i] = i*dlat-90


    # Convert to 2-D grids
    llons, llats = np.meshgrid(lons, lats)

    # Get x-y projection points on the plane
    x, y = m(llons, llats)

    # Do some interpolation
    # This is necessary for moderately-sized and large shell slices (ell_max >= 255)
    nx = int((m.xmax-m.xmin)/2000.)+1; ny = int((m.ymax-m.ymin)/2000.)+1
    nx = 1024
    ny = 1024
    print('interpolating...')
    topodat,x,y =\
    m.transform_scalar(data,lons,lats,nx,ny,returnxy=True,masked=True,order=1)
    print ('...complete...')

    #Initialize the window
    plt.figure(figsize=(xpixels/100.0, ypixels/100.0))

    #View the data
    my_cmap = plt.cm.RdYlBu_r
    img=m.pcolormesh(x,y,topodat,cmap=my_cmap)

    # draw parallels and meridians.
    m.drawparallels(np.arange(-90.,120.,30.))
    m.drawmeridians(np.arange(0.,420.,60.))
    m.drawmapboundary(fill_color='white')

    #colorbar ...
    cbar = m.colorbar(img) # ,shrink=0.5, aspect = 15)
    cbar.set_label('nondimensional')

    tick_locator = ticker.MaxNLocator(nbins=5)
    cbar.locator = tick_locator
    cbar.update_ticks()
    cbar.ax.tick_params(labelsize=cbfsize)   #font size for the ticks

    t = cbar.ax.xaxis.label
    t.set_fontsize(cbfsize)  # font size for the axis title

    plt.title('Radial Velocity')

    if (save_figure):
        plt.savefig(figure_file, fontsize=tsize)
    else:
        plt.show()
except:
    print('Basemap module is not installed.')

Basemap module is not installed.

VIII. Spherical Harmonic Spectra¶

Summary: Spherical Harmonic Spectra sampled at discrete radii.

Subdirectory: Shell_Spectra

main_input prefix: shellspectra

Python Classes:

Shell_Spectra : Complete data structure associated with Shell_Spectra outputs.
PowerSpectrum : Reduced data structure – contains power spectrum of velocity and/or magnetic fields only.

Additional Namelist Variables:

shellspectra_levels (indicial) : indices along radial grid at which to output spectra.
shellspectra_levels_nrm (normalized) : normalized radial grid coordinates at which to output spectra.

The shell-spectra output type allows us to examine the spherical harmonic decomposition of output variables at discrete radii.

Examining the main_input file, we see that the following output values have been denoted for the Shell Spectra (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity

Spherical harmonic spectra can be read into Python using either the Shell_Spectra or PowerSpectrum classes.

The Shell_Spectra class provides the full complex spectra, as a function of degree ell and azimuthal order m, for each specified output variable. It possesses an attribute named lpower that contains the associated power for each variable, along with its m=0 contributions separated and removed.

The Power_Spectrum class can be used to read a Shell_Spectra file and quickly generate a velocity or magnetic-field power spectrum. For this class to work correctly, your file must contain all three components of either the velocity or magnetic field. Other variables are ignored (use Shell_Spectrum’s lpower for those).

We illustrate how to use these two classes below. As usual, we call the help() function to display the docstrings that describe the different data structures embodied by each class.

[23]:

import matplotlib.pyplot as plt
from matplotlib import ticker
import numpy
from rayleigh_diagnostics import Shell_Spectra, Power_Spectrum
istring = '00040000'


tind = 0
rind = 0
#help(ss)

vpower = Power_Spectrum(istring)
help(vpower)
power = vpower.power

fig, ax = plt.subplots(nrows=3, figsize=(6,6))
ax[0].plot(power[:,rind,tind,0])
ax[0].set_xlabel(r'Degree $\ell$')
ax[0].set_title('Velocity Power (total)')


ax[1].plot(power[:,rind,tind,1])
ax[1].set_xlabel(r'Degree $\ell$')
ax[1].set_title('Velocity Power (m=0)')

ax[2].plot(power[:,rind,tind,2])
ax[2].set_xlabel(r'Degree $\ell$')
ax[2].set_title('Velocity Power ( total - {m=0} )')

plt.tight_layout()
plt.show()

fig, ax = plt.subplots()
ss = Shell_Spectra(istring)
help(ss)
mmax = ss.mmax
lmax = ss.lmax
power_spectrum = numpy.zeros((lmax+1,mmax+1),dtype='float64')

for i in range(1,4):   # i takes on values 1,2,3
    qind=ss.lut[i]
    complex_spectrum = ss.vals[:,:,rind,qind,tind]
    power_spectrum = power_spectrum+numpy.real(complex_spectrum)**2 + numpy.imag(complex_spectrum)**2

power_spectrum = numpy.transpose(power_spectrum)

tiny = 1e-6
img=ax.imshow(numpy.log10(power_spectrum+tiny), origin='lower')
ax.set_ylabel('Azimuthal Wavenumber m')
ax.set_xlabel(r'Degree $\ell$')
ax.set_title('Velocity Power Spectrum')

#colorbar ...
cbar = plt.colorbar(img) # ,shrink=0.5, aspect = 15)
cbar.set_label('Log Power')

tick_locator = ticker.MaxNLocator(nbins=5)
cbar.locator = tick_locator
cbar.update_ticks()
cbar.ax.tick_params()   #font size for the ticks


plt.show()

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-756e714d90d4> in <module>
     10 #help(ss)
     11
---> 12 vpower = Power_Spectrum(istring)
     13 help(vpower)
     14 power = vpower.power

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in __init__(self, infile, dims, power_file, magnetic, path)
   1337             self.blank_init(dims)
   1338         else:
-> 1339             self.spectra_file_init(path+'/'+infile)
   1340
   1341     def blank_init(self,dims):

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in spectra_file_init(self, sfile)
   1407     def spectra_file_init(self,sfile):
   1408
-> 1409         a = Shell_Spectra(filename=sfile,path='./')
   1410         lmax = a.lmax
   1411         nr = a.nr

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in __init__(self, filename, path)
   1247         else:
   1248             the_file = path+filename
-> 1249         fd = open(the_file,'rb')
   1250         # We read an integer to assess which endian the file was written in...
   1251         bs = check_endian(fd,314,'int32')

FileNotFoundError: [Errno 2] No such file or directory: './Shell_Spectra/00040000'

IX. Point Probes¶

Summary: Point-wise sampling of desired output variables.

Subdirectory: Point_Probes

main_input prefix: point_probe

Python Class: Point_Probes

Additional Namelist Variables:

point_probe_r : radial indices for point-probe output
point_probe_theta : theta indices for point-probe output
point_probe_phi : phi indices for point-probe output
point_probe_r_nrm : normalized radial coordinates for point-probe output
point_probe_theta_nrm : normalized theta coordinates for point-probe output
point_probe_phi_nrm : normalized phi coordinates for point-probe output
point_probe_cache_size : number of time-samples to save before accessing the disk

Point-probes allow us to sample a simulation at an arbitrary set of points. This output type serves two purposes: 1. It provides an analog to laboratory measurements where slicing and averaging are difficult, but taking high-time-cadence using (for example) thermistors is common-practice. 2. It provides an alternative method of slicing a model ( for when equatorial, meridional, or shell slices do yield the desired result).

IX.1 Specifying Point-Probe Locations¶

Point-probe locations are indicated by specifying a grid. The user does not supply a set of ordered coordinates (r,theta,phi). Instead, the user specifies nodes on the grid using the namelist variables described above. Examples follow.

**Example 1: 4-point Coarse Grid **

point_probe_r_nrm = 0.25, 0.5
point_probe_theta_nrm = 0.5
point_probe_phi_nrm = 0.2, 0.8

This example would produce point probes at the four coordinates { (0.25, 0.5, 0.2), (0.25, 0.5, 0.8), (0.5, 0.5, 0.2), (0.5,0.5,0.8) } (r,theta,phi; normalized coordinates).

**Example 2: “Ring” in Phi **

point_probe_r_nrm = 0.5
point_probe_theta_nrm = 0.5
point_probe_phi_nrm = 0.0, -1.0

This example describes a ring in longitude, sampled at mid-shell, in the equatorial plane. We have made use of the positional range feature here by indicating normalized phi coordinates of 0.0, -1.0. Rayleigh intreprets this as an instruction to sample all phi coordinates.

** Example 3: 2-D Surface in (r,phi) **

point_probe_r_nrm = 0, -1.0
point_probe_theta_nrm = 0.25
point_probe_phi_nrm = 0, -1.0

This example uses the positional range feature along with normalized coordinates to generate a 2-D slice in r-phi at theta = 45 degrees (theta_nrm = 0.25). Using the syntax 0,-1.0 instructs Rayleigh to grab all r and phi coordinates.

** Example 4: 3-D Meridional “Wedges” **

point_probe_r_nrm = 0.0, -1.0
point_probe_theta_nrm = 0.0, -1.0
point_probe_phi_nrm = 0.20, -0.30, 0.7, -0.8

This example generates two 3-D wedges described by all r,theta points and all longitudes in the ranges [72 deg, 108 deg] and [252 deg, 288 deg].

IX.2 Point-Probe Caching¶

When performing sparse spatial sampling using point-probes, it may be desireable to output with a high-time cadence. As this may cause disk-access patterns characterized by frequent, small writes, the point-probes are programmed with a caching feature. This feature is activated by specifing the point_probe_cache_size variable in the output namelist.

This variable determines how many time-samples are saved in memory before a write is performed. Its default value is 1, which means that the disk is accessed with a frequency of point_probe_frequency. If the cache size is set to 10 (say), then samples are still peformed at point_probe_frequency but they are only written to disk after 10 have been collected in memory.

NOTE: Be sure that point_probe_cache_size divides evenly into point_probe_nrec.

IX.3 Example: Force-Balance with Point Probes¶

Our example input file specifies a coarse, six-point grid. Examining the main_input file, we see that all variables necessary to examine the force balance in each direction have been specified. (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity
1201	Radial Advection (v dot grad v)
1202	Theta Advection
1203	Phi Advection
1216	Buoyancy Force (ell=0 component subtracted)
1219	Radial Coriolis Force
1220	Theta Coriolis Force
1221	Phi Coriolis Force
1228	Radial Viscous Force
1229	Theta Viscous Force
1230	Phi Viscous Force

Note that the pressure force appears to be missing. This is not an oversight. The diagnostic nature of the Pressure equation in incompressible/anelastic models, coupled with the second-order Crank-Nicolson time-stepping scheme, means that the pressure field can exhibit an even/odd sawtoothing in time. The effective pressure force (as implemented through the Crank-Nicolson scheme) is always a weighted average over two time steps and is always well-resolved in time.

When sampling at regular intervals as we have here, if we directly sample the pressure force, we will sample either the high or low end of the sawtooth envelope, and the force balance will be off by a large factor. The easiest fix is to output the velocity field and compute its time derivative. This, in tandem with the sum of all other forces, can be used to calculate the effective pressure as a post-processing step. The (undesireable) alternative is to output once every time step and compute the effective pressure using the Crank-Nicolson weighting.

We demonstrate how to compute the effective pressure force via post-processing in the example below.

[24]:

from rayleigh_diagnostics import Point_Probes,  build_file_list
import numpy
from matplotlib import pyplot as plt

#Decide which direction you want to look at (set direction = {radial,theta, or phi})
#This is used to determine the correct quantity codes below
radial = 0
theta  = 1
phi    = 2
direction=radial
# Build a list of all files ranging from iteration 0 million to 1 million
files = build_file_list(0,1000000,path='Point_Probes')
nfiles = len(files)-1


for i in range(nfiles):
    pp = Point_Probes(files[i],path='')
    if (i == 0):
        nphi = pp.nphi
        ntheta = pp.ntheta
        nr = pp.nr
        nq = pp.nq
        niter = pp.niter
        vals=numpy.zeros( (nphi,ntheta,nr,nq,niter*nfiles),dtype='float64')
        time=numpy.zeros(niter*nfiles,dtype='float64')
    vals[:,:,:,:, i*niter:(i+1)*niter] = pp.vals
    time[i*niter:(i+1)*niter]=pp.time
istring='00040000' # iteration to examine
help(pp)
##################################################
# We choose the coordinate indices **within**
# the Point-Probe array that we want to examine
# These indices start at zero and run to n_i-1
# where n_i is the number of points sampled in
# the ith direction

# Use help(pp) after loading the Point-Probe file
# to see the Point-Probe class structure

pind = 0           # phi-index to examine
rind = 0           # r-index to examine
tind = 0           # theta-index to examine


pp   = Point_Probes(istring)
lut  = pp.lut

nt   = pp.niter


#######################################################################
#  Grab velocity from the point probe data
u  = vals[pind,0,rind,pp.lut[1+direction],:]
dt=time[1]-time[0]


###########################################################################
# Use numpy to compute time-derivative of u
# (necessary to compute a smooth effective pressure without outputing every timestep)

#Depending on Numpy version, gradient function takes either time (array) or dt (scalar)
try:
    dudt = numpy.gradient(u,time)
except:
    dt = time[1]-time[0]  # Assumed to be constant...
    dudt = numpy.gradient(u,dt)



################################################################
#      Forces (modulo pressure)
# Note the minus sign for advection.  Advective terms are output as u dot grad u, not -u dot grad u
advec = -vals[ pind, tind, rind, lut[1201 + direction], :]
cor   = vals[ pind, tind, rind, lut[1219 + direction], :]
visc  = vals[ pind, tind, rind, lut[1228 + direction], :]
forces = visc+cor+advec
if (direction == radial):
    buoy  = vals[ pind, tind, rind, lut[1216], :]
    forces = forces+buoy


############################################3
# Construct effective pressure force
pres = dudt-forces
forces = forces+pres
############################################################
# Set up the plot
yfsize='xx-large'  # size of y-axis label

ustrings = [r'u_r', r'u_\theta', r'u_\phi']
ustring=ustrings[direction]
dstring = r'$\frac{\partial '+ustring+'}{\partial t}$'
fstrings = [r'$\Sigma\,F_r$' , r'$\Sigma\,F_\theta$' , r'$\Sigma\,F_\phi$' ]
fstring = fstrings[direction]
diff_string = dstring+' - '+fstring

pstring = 'pressure'
cstring = 'coriolis'
vstring = 'viscous'
bstring = 'buoyancy'
fig, axes = plt.subplots(nrows=2, figsize=(7*2.54, 9.6))
ax0 = axes[0]
ax1 = axes[1]


########################################
# Upper: dur/dt and F_total
#mpl.rc('xtick', labelsize=20) --- still trying to understand xtick label size etc.
#mpl.rc('ytick', labelsize=20)

ax0.plot(time,forces, label = fstring)
ax0.plot(time,pres,label=pstring)
ax0.plot(time,cor,label=cstring)
ax0.plot(time,visc,label=vstring)
if (direction == radial):
    ax0.plot(time,buoy,label=bstring)
ax0.set_xlabel('Time', size=yfsize)

ax0.set_ylabel('Acceleration', size=yfsize)
ax0.set_title('Equilibration Phase',size=yfsize)
ax0.set_xlim([0,0.1])
leg0 = ax0.legend(loc='upper right', shadow=True, ncol = 1, fontsize=yfsize)

##########################################
# Lower:  Numpy Gradient Approach
ax1.plot(time,forces,label=fstring)
ax1.plot(time,pres,label=pstring)
ax1.plot(time,cor,label=cstring)
ax1.plot(time,visc,label=vstring)
if (direction == radial):
    ax1.plot(time,buoy,label=bstring)
ax1.set_title('Late Evolution',size=yfsize)
ax1.set_xlabel('Time',size=yfsize)
ax1.set_ylabel('Acceleration', size =yfsize)
ax1.set_xlim([0.2,4])
leg1 = ax1.legend(loc='upper right', shadow=True, ncol = 1, fontsize=yfsize)


plt.tight_layout()
plt.show()

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-11ad19ac97c9> in <module>
     10 direction=radial
     11 # Build a list of all files ranging from iteration 0 million to 1 million
---> 12 files = build_file_list(0,1000000,path='Point_Probes')
     13 nfiles = len(files)-1
     14

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in build_file_list(istart, iend, path, diter, ndig, special)
   1501     if (diter < 1):
   1502         # Examine the directory and grab all files that fall between istart and iend
-> 1503         allfiles = os.listdir(path)
   1504         allfiles.sort()
   1505         for f in allfiles:

FileNotFoundError: [Errno 2] No such file or directory: 'Point_Probes'

X. Modal Outputs¶

Summary: Spherical Harmonic Spectral Coefficients sampled at discrete radii and degree ell.

Subdirectory: SPH_Modes

main_input prefix: sph_mode

Python Classes: SPH_Modes

Additional Namelist Variables:

sph_mode_levels (indicial) : indices along radial grid at which to output spectral coefficients.
sph_mode_levels_nrm (normalized) : normalized radial grid coordinates at which to output spectral coefficients.
sph_mode_ell : Comma-separated list of spherical harmonic degree ell to output.

The Modal output type allows us to output a restricted set of complex spherical harmonic coefficients at discrete radii. For each specified ell-value, all associated azimuthal wavenumbers are output.

This output can be useful for storing high-time-cadence spectral data for a few select modes. In the example below, we illustrate how to read in this output type, and we plot the temporal variation of the real and complex components of radial velocity for mode ell = 4, m = 4.

Examining the main_input file, we see that the following output values have been denoted for the Shell Spectra (see rayleigh_output_variables.pdf for mathematical formulae):

Menu Code	Description
1	Radial Velocity
2	Theta Velocity
3	Phi Velocity

We also see that ell=2,4,8 have been selected in the main_input file, leading to power at the following modes:

ell-value	m-values
2	0,1,2
4	0,1,2,3,4
8	0,1,2,3,4,5,6,7,8

[25]:

from rayleigh_diagnostics import SPH_Modes, build_file_list
import matplotlib.pyplot as plt
import numpy

qind = 1  # Radial velocity
rind = 0  # First radius stored in file


files = build_file_list(0,1000000,path='SPH_Modes')
nfiles = len(files)
for i in range(nfiles):
    spm = SPH_Modes(files[i],path='')
    if (i == 0):
        nell = spm.nell
        nr = spm.nr
        nq = spm.nq
        niter = spm.niter
        lvals = spm.lvals
        max_ell = numpy.max(lvals)
        nt = niter*nfiles
        vr = spm.lut[qind]
        vals=numpy.zeros( (max_ell+1,nell,nr,nq,nt),dtype='complex64')
        time=numpy.zeros(nt,dtype='float64')
    vals[:,:,:,:, i*niter:(i+1)*niter] = spm.vals
    time[i*niter:(i+1)*niter]=spm.time
help(spm)
#####################################################3
# Print some information regarding the bookkeeping
print('...........')
print(' Contents')
print('  nr = ', nr)
print('  nq = ', nq)
print('  nt = ', nt)
for i in range(nell):
    lstring=str(lvals[i])
    estring = 'Ell='+lstring+' Complex Amplitude : vals[0:'+lstring+','+str(i)+',0:nr-1,0:nq-1,0:nt-1]'
    print(estring)
print(' First dimension is m-value.')
print('...........')

######################################
# Create a plot of the ell=4, m=4 real and imaginary amplitudes
radius = spm.radius[rind]
lfour_mfour = vals[4,1,rind,vr,:]
fig, ax = plt.subplots()
ax.plot(time,numpy.real(lfour_mfour), label='real part')
ax.plot(time,numpy.imag(lfour_mfour), label='complex part')
ax.set_xlabel('Time')
ax.set_ylabel('Amplitude')
rstring = "{0:4.2f}".format(radius)
ax.set_title(r'Radial Velocity ( $\ell=4$ , m=4, radius='+rstring+' ) ')
ax.legend(shadow=True)
ax.set_xlim([0.5,4.0])
plt.show()

---------------------------------------------------------------------------
FileNotFoundError                         Traceback (most recent call last)
<ipython-input-1-bbf64180bdd0> in <module>
      7
      8
----> 9 files = build_file_list(0,1000000,path='SPH_Modes')
     10 nfiles = len(files)
     11 for i in range(nfiles):

~/checkouts/readthedocs.org/user_builds/gassmoeller-rayleigh/checkouts/deduplicate_citation/post_processing/rayleigh_diagnostics.py in build_file_list(istart, iend, path, diter, ndig, special)
   1501     if (diter < 1):
   1502         # Examine the directory and grab all files that fall between istart and iend
-> 1503         allfiles = os.listdir(path)
   1504         allfiles.sort()
   1505         for f in allfiles:

FileNotFoundError: [Errno 2] No such file or directory: 'SPH_Modes'

[ ]:

Contents¶

I. Running a Benchmark with Sample Output¶

II. Configuring Your Python Environment¶

Conda Installation on Linux Systems¶

Preparing to Plot¶

The Jupyter Notebook¶

III. Overview of Diagnostics in Rayleigh¶

Basic Output Control¶

Positional Output Control¶

IV. Global Averages¶

The Lookup Table (LUT)¶

Plotting Kinetic Energy¶

V. Shell Averages¶

Velocity vs. Radius¶

Radial Temperature Profile¶

Heat Flux Contributions¶

VI. Azimuthal Averages¶

VII. Simulation Slices¶

VII.1 Equatorial Slices¶

VII.2 Meridional Slices¶

VII.3 Shell Slices¶

VIII. Spherical Harmonic Spectra¶

IX. Point Probes¶

IX.1 Specifying Point-Probe Locations¶

IX.2 Point-Probe Caching¶

IX.3 Example: Force-Balance with Point Probes¶

Rayleigh

Navigation

Related Topics
